Super 9 Plus SIRIO 141 cm

Super 9 Plus SIRIO 141 cm CB Vehicle Antenna 85 cm

A mobile CB antenna with a length of 1415 mm, mounted to the joint via a wing nut (therefore, the antenna can also be used on a DV magnet).
The antennas are supplied with joints for the NE connector, which has a 12 mm mounting hole and a connector height of 15 mm below the joint.
This type of connector is particularly suitable for indoor use (it is not moisture-resistant).
The second type of joint is the NF, which has a mounting hole of 8 mm and a connector height of 35 mm below the joint.
This type of connector is suitable for outdoor use (clamps, fasteners, etc.).
Maximum short-term power handling: 150 W; long-term power handling: 30 W; vertical polarization; 4-meter RG58 cable; mounting hole diameter: 12.5 mm.


TECHNICAL
PARAMETERS-------------

-------------------------------- Impedance ..............................................50 ohms -
Frequency range ................................... 27–28.5
MHz - Polarization ................................................
vertical- S.W.R. ......................................................1.2:1
- Bandwidth............................................1900 kHz
- Maximum power.....................................30 watts continuous / 150 watts
peak- Antenna length.......................................... 1415 mm
—Antenna weight.....................................410 g
—Mounting hole........................................12 mm NF joint type / 8 mm
NE joint type- Connector height below the base ....................15 mm NE joint / 35 mm NF


joint.

The station connector is not included. For shipping via a courier service, a surcharge starting at 40 CZK (excluding VAT) applies for special packaging.
